Specification
Characteristics of Conveyor Beltings
Nylon/Nylon (NN) Carcass
- Lower longitudinal elongation
- Higher tensile strength
- Good flexibility and troughability
- Good resistance to mildew, moisture and rotting
- Good resistance to edge wear
- Excellent impact resistance
- Unaffected by alkalis and weak acids
- Suitable for conveying material over long distances
- Cotton / Cotton (CC) Carcass
- Suitable for most applications
- Good bonding for rubber
- Good fastener holding properties
Cotton / Cotton (CC) Carcass
- Suitable for most applications
- Good bonding for rubber
- Good fastener holding properties
Cotton / Nylon (CN) Carcass
- Good troughability
- Resistance to longitudinal tearing and damage due to edge turn up
- Improved resistance to impact damage
- Lighter in weight
- Better mechanical fastener holding properties
Polyester/Nylon (EP) Carcass
Besides having the advantages as listed for NN carcass belts, EP belts have the additional advantage of lower longitudinal elongation.
Conveyor Belt Range
| Width | Upto 1600mm |
|---|---|
|
Length |
Open or endless upto 350 mtrs in single length with cut edge or moulded edge |
|
Fabric Piles |
2 piles to 8 piles in Polyster / Nylon (Ep), Nylon/
Nylon (NH), Coton/Nylon (CN) or Cotton/Cotton (CC) |
|
Cover Grades |
M-24, N-17, HR, SHR, UHR, OR, Hygienic, CMR & FR. |
|
Cover Thickness |
As per Customer Specification |
| Specification and Technical Data of Multiply Nylon Conveyor Belt | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Strength Classes and number of piles | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Strength Classes | 2-PLY | 3-PLY | 4-PLY | 5-PLY | 6-PLY | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
